M8 4Pin Female Connector
The M8 connector is used specifically with industrial sensors and features a waterproof 3-pin screw. These connectors come pre-assembled and remain watertight even if submerged and they are typically used in harsh environments. Common applications for the M8 connector include actuators, PLCs, I/O boxes, sensors, and switches in food and beverage processing, machine building, rubber and plastics, textile and printing presses, and HVAC system valves.
Item No. : WP-04F2-16
Features :
- Alternative mount arrangements for solder cup or PCB
- Panel Mount and distribution version available
- Shield reliable
- Quick and secure connection
- Backward compatible
- Degree of protection up to IP67 for safe use in harsh environment
- Acceptable for MOQ order
- OEM & ODM orders are welcomed to meet your customized requirement
Description
No. of Contacts | 4 Pins |
Connector Gender | Female Connector |
Coding | A code |
Orientation | Straight |
Wire Termination | Soldering |
Housing Material | PBT UL94V-0, Black |
Contact Material | Bronze with gold plated underplated Nickel |
Nut Material | Brass with Nickel plated |
O-ring Material | NBR, Black |
Rated Current | 5A |
Rated Voltage | 125V |
Waterproof Rating | IP67 |
Operation Temperature | -40℃ ~ 85℃ |
